300w co2 laser cutter
- #1,Automatic following cutting head.
- #2, Output 300W~600W co2 laser power.
- #3, High precision gear and rack transmission system.
Get Our Best Quotes
Please Fill in the Form Below and Our Engineers Will Respond within 24 Hours
What is 1325 mix laser cutting and engraving machine & 300w co2 laser cutter？
♦ The 1325 hybrid laser cutting machine can be customized according to customer requirements and equipped with high-power CO2 laser tubes such as 150w, 300w, 500w, and 600w.
♦ This laser-cutting machine is mainly used for processing non-metallic materials such as acrylic, wood, fabric, leather, foam, sponge, rubber, cardboard, etc. It can also process metal materials with a thickness ≤ 3mm, such as stainless steel, carbon steel, galvanized sheet, titanium sheet, etc. For example, stainless steel plate, carbon steel plate, galvanized plate, titanium plate, etc.
Machine Features of 300w CO2 mixed Laser Cutting Machine
The 300w co2 laser cutter/Dekcel is one of the market’s most efficient and advanced laser cutters
Laser Power
It is available with 150w,300w, and 600w co2 laser tubes, and the output laser power is strong and stable, the processing accuracy is high, the cutting effect is perfect, and there is no after-sales service.
Auto-focus following cutting head
The following type of cutting system automatically selects the optimum focus, ensuring the best focusing effect and cutting effect to avoid cut inconsistencies due to uneven material and different thicknesses.
Rack and pinion transmission system
The Y-axis of the machine adopts a double rack drive, stable operation, high precision, and fast cutting speed.
What can a 300W CO2 laser cut?
The 300w co2 laser cutter &mixed laser cutter machine is suitable for cutting and cutting various non-metallic and metal sheets such as wood, MDF, acrylic, plywood, stainless steel, carbon steel, galvanized steel, etc. It is widely used in signs, models, and advertising applications.
Technical Parameter of 300w co2 laser cutter
| Model | DEK-1325J | DEK-1530J |
|---|---|---|
| Work Area (mm) | 1300mm*2500mm | 1500mm*3000mm |
| Laser Generator | Co2 glass sealed laser tube | |
| Laser Power | 150W/300W/500W/600W | |
| Transmission | Belt / Gear and rack with servo motor | |
| Cutting Head | Auto focus following head | |
| Material | Wood : ¡Ü30mm / Acrylic :¡Ü 30mm / Foam : ¡Ü100mm | |
| Carbon steel : ¡Ü4mm / Stainl steel : ¡Ü3mm | ||
| Control System | Ruida laser controller | |
| Cutting Speed | 0-48000mm/min | |
| Resolution | <0.025mm | |
| Power Supply | AC110V/220V¡À 10%,50-60Hz | |
| Software supported | PLT, AI,JPGE, PCS, TGA, DST, DXP, DXF, DWG, CDR | |
| Design?Software | CORELDRAW,?PHOTOSHOP,?AUTOCAD,SOLIDWORKS | |
| Cooling Type | CW-6000 dual temperature dual control water chiller | |
| Accessories | Water Chiller, Air Pump, Exhaust Blower |
